Product Description

Technical Principles:

• PDLC film in the absence of an electric field,the electronically controlled smart film is in an opaque state.When an alternating current is applied, the liquid crystal molecules are arranged in an orderly manner, at which point the electrically controlled dimming film changes from an opaque state (OFF) to a transparent state (ON).
• PNLC film different from normal PDLC smart film,the working principle of PNLC film is opaque-power on,clear power off. The electric field enables a rapid transition from the ON state to the OFF state and from the OFF state to the ON state.Smart film is usually applied to the surface of the glass or laminated between the glass layers, making the otherwise transparent glass, more possible.
• Polymer Dispersed Liquid Crystal Smart films is commented the most advanced curtain today and future,designed new or retrofit an existing space for an instant upgrade，instantly switching from opaque to transparent for dynamic light control with a HD real projection function ,widely used in interior and architectural design, commercial center ,rail transportation, and even avant-garde industrial products.

Specifications:

Product:

• Items
  • Thickness
    • Total thickness (without protective film) 3.13
    • PDLC 0.12mm
    • Silica gel 0.01mm
    • PE protective film 130μm
    • PET release film 50μm
  •  Sheet
    • Width: 1200,1500¹*mm
    • Length: According to customer requirements
  • Roll
    • Width: 1250,1500²*mm
    • Length: ≤ 50m/Roll
  • Roll tube
    • Inner Diameter: 6 inches

Photoelectric Performance:

• Items:
  • Operating voltage:
    • ON/OFF
      • ON 60V
    • Test Methods/Standards
    • Multimeter/Voltage Regulator,WGW
  • Power consumption:
    • ON/OFF
      • ON ≤ 5W/m2
    • Test Methods/Standards
      • Multi-parameter electric measuring instrument
  • Viewing angle:
    • ON/OFF
      • ON ≥ 160°
    • Test Methods/Standards
      • Visual Inspection
  • Uv blocking rate:
    • ON/OFF
      • OFF ≥ 99%
    • Test Methods/Standards
      • Optical teansmittance tester
  • Infrared blocking rate:
    • ON/OFF
      • OFF ≥ 82%
    • Test Methods/Standards
      • Optical teansmittance tester
  • Response time:
    • ON/OFF
      • OFF→ON ≤ 30 ms
      • ON→OFF ≤ 200 ms
    • Test Methods/Standards
      • Liquid crystal parameter integrated tester
      • Liquid crystal parameter integrated tester
  • Operating temperature
    • ON/OFF
      • – -30°C ~95°C
    • Test Methods/Standards
      • constant temperature and humidity testing machine
  • Life-span
    • ON/OFF
      • 10 -15 years
    • Test Methods/Standards
      • GB18910.5-2008
  • Switching times
    • ON/OFF
      • ≥ 100 ten thousand Times
    • Test Methods/Standards
      • Self-made on/off tester

Product Transparency / Haze

• • Item
    • Adhesive PDLC film
      • Full light tester
        • ON/OFF
          • OFF
          • ON
        • Haze
          • 94.2
          • 2.94
        • Full light transmittance
          • 51.19
          • 56.43
        • b value
          • 5.24
          • 3.20
      • Parallel light tester
        • 45° light
          • /
          • 38.4
        • Parallel light
          • /
          • 55.26
