Product Description

Features:

• 13-Inch Full HD Display (1920 × 1080): Produces sharp, vibrant, and detailed imagery for professional digital signage use.
• ADS Panel Technology: Provides accurate color reproduction and consistent brightness across ultra-wide 170° viewing angles.
• High Brightness – 500 Nits: Ideal for high-visibility areas such as retail counters, lobbies, and information kiosks.
• Powered by Tizen 7.0 OS: Advanced smart signage platform for stable operation, app integration, and secure content playback.
• All-in-One Connectivity: Supports Wi-Fi, Bluetooth, HDMI 1.4, USB, RJ45, and RS232 connections for maximum flexibility.
• Compact and Lightweight Design: Only 0.8 kg in weight, making it easy to install in tight spaces or as part of a multi-screen setup.
• Energy Efficient: Consumes just 35W during operation for sustainable, low-cost performance.
• Durable & Reliable Build: Engineered for 16/7 continuous operation with EMC Class B and Safety 62368-1 certifications.
• Flexible Mounting Options: VESA 100 × 100 mm compatibility allows easy wall or stand installation.
• Integrated Audio Out: Includes stereo mini-jack for clear sound output when needed.

Specifications

• Display Size: 13 inches
• Resolution: 1920 × 1080 (Full HD)
• Panel Type: ADS
• Brightness (Typical): 500 nits
• Contrast Ratio (Static): 800:1
• Dynamic Contrast Ratio: 10,000:1
• Color Gamut: 45%
• Response Time: 30 ms
• Viewing Angle (H/V): 170° / 170°
• Pixel Pitch (H×V): 0.153 × 0.153 mm
• Glass Haze: 25%
• Operating Hours: 16/7
• Connectivity: HDMI 1.4 (1x), USB (1x), RS232 In, RJ45, Wi-Fi, Bluetooth
• Audio Output: Stereo Mini Jack
• Power Supply: AC 100–240V, 50/60Hz
• Power Consumption (Typical): 35W
• Sleep Mode Power: 0.5W
• Dimensions (W×H×D): 322 × 193.5 × 19.9 mm
• Weight (Set): 0.8 kg
• Operating Temperature: 0°C to 40°C
• Humidity: 10–80% (non-condensing)
• Mounting: VESA 100 × 100 mm
• Bezel Color / Width: Black / 12.1 mm
• Frame Finish: Non-glossy
• Operating System: Tizen 7.0
• Internal Memory: 8GB Flash
• Certifications: EMC Class B, Safety 60950-1 / 62368-1
• Included Accessories: Simple Stand (2 pcs), Power Cable
• Optional Accessories: Wall Mount (WMN-2090SC)
