LG LAPA163-GF 163″ LED All-in-One Led Signage
- Screen Size : 163″
- Pixel Pitch : 1.88 mm
- Brightness : 500 nit (Max., after calibration)
- Screen Resolution : 1,920 × 1,080
Product Description
PHYSICAL PARAMETERS
- Pixel Configuration: Single SMD
- Pixel Pitch (mm): 1.88
- Module Resolution (WxH): 160*90
- Module Dimensions(WxH,mm): 300*168.75
- No. of Modules per Screen (WxH): 12 × 12 (Total 144)
- Screen Resolution (WxH): 1,920 × 1,080
- Screen Dimensions (W x H x D, mm, including bezel): 3,605 x 2,030 x 29.95 (Thickest 59.5)
- Screen Surface Area (㎡): 7.29
- Weight of the screen: 155
- Physical Pixel Density (pixels/㎡): 284,444
- Flatness of Cabinet (mm): ±0.15 (TBD)
- Cabinet material: Aluminum
- Service access: Front
OPTICAL SPECIFICATIONS
- Max. Brightness (After Calibration): Typ. 500
- Color Temperature: 3,200~9,300
- Visual Viewing Angle (Horizontal): 150
- Visual Viewing Angle (Vertical): 150
- Brightness Uniformity(%): 0.98
- Color Uniformity: ±0.015Cx,Cy
- Contrast Ratio: 3,000:1
- Processing Depth (bit): 16
ELECTRICAL SPECIFICATIONS
- Power Consumption (W/Screen, Max.): 2,000
- Power Consumption (W/Screen, Avg.): 750
- Power Consumption (W/㎡, Max.): 275
- Heat Dissipation (BTU/h/Screen, Max.): 6,825
- Heat Dissipation (BTU/h/Screen, Avg.): 2,560
- Heat Dissipation (BTU/h/㎡, Max.): 939
- Power Supply (V): 100 to 240
- Frame Rate (Hz): 50 / 60
- Refresh Rate (Hz): 3,840
OPERATION SPECIFICATIONS
- LED Lifetime (Half brightness): 100,000
- Operating Temperature(℃): 0℃ to +40℃
- Operating Humidity: 10~90%RH
- IP rating Front: IP30
- IP rating Rear: IP30
