General

• Model: 65WF25E
• Screen size: 65″
• Screen Active Area(mm): 1428.48 x 803.52
• Resolution : FHD (1920×1080)
• Aspect Ratio: 16:9
• Brightness(nit): 2500nits
• Contrast Ratio: 4000:1
• Dynamic CR: Up to 250000:1
• Viewing Angle(H/V): 178°/178°
• Backlight Life Cycle: 50,000 Hrs
• Operation Hours: 24/7
• Response Time: 8ms
• Screen Orientation: Portrait or Landscape

System

• OS: Android 9.0
• CPU: ARM Quad Core Cortex-A53 1.5G
• GPU: Arm Mali-G52 2EE MC1
• DDR: DDR 2GB
• ROM: 16GB EMMC
• Language: Chinese/English

Connectivity

• Input: USB2.0 x2, HDMI IN x2, Ethernet RJ45 x2, RS232 RJ45 x1, IR in x1, Sensor x1
• Output: HDMI Out x1, Audio out x1

Network connection

• Wifi or LAN: Yes
• 3G/4G connection: Optional

Speaker

• Build in speaker: Yes
• Line-out Support: Yes
• BT Speaker Support: Yes

Thermal management

• Smart Backlight Control: Yes
• Smart Temperature Control: Yes
• Smart Fans Control: Fanless
• Smart Monitoring System Cloud: Optional / CetusMSC
• Overheating protection: Yes

Physical

• IP rating: IP5X (Front Panel)
• Glass: No
• Shell: Aluminum
• Standard Color: Black
• Bezel width(T/L/R/B): 10mm(T/B/L/R)
• Dimensions: 1450.88(H) x 826.22(W) x 56.75(D) mm
• Packing Dimensions(W×H×D): 1611(W) x 978(H) x 180(D) mm
• VESA: 400×300

Operation

• Working environment: Indoor window facing
• Auto Brightness control: Light sensor
• Operation Temperature (ambient temp.): -10oc to 35oc (Direct Sunlight) -10oc to 45oc (w/o Direct Sunlight)
• Operation Humidity: 10% to 80%
• Storage Temperature: -10oc to +60oc
• Storage Humidity: 10% to 80%

Power

• Power Supply: AC 110 /220V,50/60Hz
• Power Type: Built-In Power
• Max: 500W
• Typical[W/h]: 305W( note:IEC 62087 measurement standard）

What’s in the box

• Accessories: Power cord \ IR receiver \ Remote Control \ AAA batteries x2 \ Wifi antenna \ Lifting ring(M6) x2 \ Filler pad(M6) x2 \ Spring pad(M6) x2 \ User manual（Electronic version）

Available Regions

• EU
• APAC
• SA
