Product Description

Overview:

• Integrated lighting and digital display — project dynamic, experiential content to engage audiences in retail, hospitality and event spaces, showrooms and museums
• Create head-turning digital signage — illuminate and project on virtually any surface or material, for digital art, commercial signage and décor applications
• Blends in discreetly — sleek, white spotlight design easily blends into its surroundings, offering vertical and horizontal rotation, with flexible mounting on tracks, floors, walls or ceilings
• Breakthrough laser technology — provides up to 20,000 hours of virtually maintenance-free operation1, plus a sealed optical engine, for amazing image quality matched by outstanding performance
• Robust management and control tools — via Epson’s Web-based application or over the network with Crestron®, Art-Net and more
• Scalable, for an array of applications — install multiple LightScene projectors and utilize Edge Blending technology for versatile, breathtaking displays
• Easily programmable — includes templates, effects, color filters and customizable options; playlist and playback function allows for seamless content management for single or multiple LightScene projectors
• Flexible positioning — 1.58x powered optical zoom, plus powered focus, allows the projector to be installed in both large and small spaces
• Expansive connectivity — HDMI®, wired and wireless LAN, and SD card slot2 for direct content storage when needed
• Bright visual display system — 2,000 lumens equal color and white brightness for vibrant, rich color.

Specifications:

Projection Lens:

• Type: Optical Zoom (Powered) / Focus (Powered)
• Focal Length: 18.2mm-28.4mm
• Zoom Ratio:
  • 1 – 2.21 (Total)
  • 1 – 1.58 (Optical Zoom)
• F-number: 1.51-1.92
• Throw Ratio Range: 1.38 – 2.19 (Wide to Tele)

Wireless Specifications (Wireless LAN: Built-in):

• Supported Speed for Each Mode :
  • IEEE 802.11b: 11 Mbps*3
  • IEEE 802.11g: 54 Mbps*3
  • IEEE 802.11n: 130 Mbps*3
• Wireless LAN Security: Quick: WPA2-PSK, Advanced: WPA/WPA-PSK
• Supported Connection Mode: Infrastructure, Access Point
• Screen Size (Projected Distance):
  • Zoom : Wide: 30″ to 150″ (0.88 to 4.51 m)
  • Zoom : Tele: 30″ to 150″ (1.41 to 7.16 m)
• Standard Size: 60″ screen 1.79m (Standard size)

Geometric Correction:

• Vertical/Horizontal Keystone: ±45° / ±40°
• Quick Corner: Yes

Operating Altitude:

• Operating Altitude: 0 m to 3048 m (0 ft to 10000 ft) (over 1500 m / 4921 ft : with High altitude mode)

Start-Up Period:

• Start-Up Period:
  • Less than 9 seconds
  • Warm-up period: 30 seconds

Direct Power On/Off:

• Direct Power On/Off: Yes / Yes

Optional Wireless & Built In Lan Specifications:

• Supported Speed for each Mode: IEEE 802.11g (2.4GHz): 54 Mbps*
• Wireless LAN Security: K

Brightness:

• White Light Output (Normal / Extended): 2000lm / 1000lm / 1000lm
• Colour Light Output: 2000lm
• Contrast Ratio: Over 5,000,000:1
• Colour Mode: Dynamic Normal
