Product Description

Technical Specification:

AMPLIFICATION:

• Maximum Peak Power, Symmetrical 20 W
• Rated Power, Symmetrical 20 W per channel, < 0.3% distortion over frequency range

AUDIO INPUTS, ANALOG:

• Connectors (1) stereo 1/8-in (3.5 mm)

COMPLIANCE:

• Safety IEC/UL/EN 60065:2014/A11:2017, IEC/UL/EN 62368-1:2014/A11:2017
• Environmental RoHS
• EMC FCC Part 15B Class B, ICES-003 Class B, CISPR 13, EN55032 Class B, EN55035, EN61000-3-2, EN61000-3-3, BSMI CNS13439

CAMERA AND VIDEO:

• Focus Distance 0.5 m (1.6 ft) to ∞
• Field of View (FOV) 123° diagonal × 115° horizontal × 81° vertical
• Image Sensor 8 MP
• Lens Up to 5x digital zoom
• Positioning Autoframing mode, manual pan-tilt-zoom (PTZ) with configurable presets
• Processing Automatic white balance, automatic brightness, digital noise reduction
• Supported Video Resolutions UHD 2160p (4K), 1080p, 720p, 960×480, 848×480, 640×480, 640×360, 432×240 (30 fps)
• USB Device Video Class (UVC) v1.1
• Video Encoding H.264, M-JPEG

COMMUNICATION PORTS:

• Bluetooth Bluetooth 4.2 HSP, A2DP, AVRCP, Bluetooth Low Energy
• Network RJ-45, 1 Gbps Ethernet, IEEE 802.3 (wired) / Wi-Fi 802.11ac (wireless)

CONTROL INPUTS:

• Inputs (Control) (1) general purpose, 2-pin Euroblock

ELECTRICAL:

• AC Power Connector External power supply with local power cord (included)
• AC Power Input 110–240 VAC, 50/60 Hz, 1.5 A maximum

GENERAL:

• System Requirements Windows 7, 8.1, or 10 / macOS 10.10 or later / Chrome OS (Google Chromebook)
• Software Applications Videobar Configuration (Windows, macOS, web browser), Videobar Administration (Windows), Videobar Mobile (Android, iOS)
• Computer Interface Connection USB Type-C (USB 3.0 UAC, UVC, HID)

MICROPHONE:

• Microphone Type, Quantity and Size 6 microphones
• Pickup Range 6.0 m (19.7 ft)
• Technology Static and adaptive dynamic beam-forming, 3 exclusion zones, stereo acoustic echo cancellation (AEC), digital noise suppression

INDICATORS AND CONTROLS:

• LED Status Indicators (1) LED light bar, (1) mute LED, (1) Bluetooth LED

PHYSICAL:

• Colors Black
• Suspension/Mounting Tabletop stand, wall-mount template, display mounting kit (optional), mud ring (optional)
• Operating Temperature Range 0 °C to 40 °C (32 °F to 104 °F), 90% non-condensing humidity
• Product Dimensions (H×W×D) 1.9 in × 27.0 in × 4.0 in (48 mm × 659 mm × 102 mm)
• Net Weight 5.6 lb (2.5 kg)
• Shipping Dimensions (H×W×D) 27.0 in × 1.9 in × 3.8 in (686 mm × 48 mm × 96 mm)
• Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F), 93% relative humidity
• Shipping Weight 12.0 lb (5.4 kg)

PERFORMANCE:

• Calculated Maximum SPL @ 1 m 89 dB (IEC 60268-5, mono input, wall-mounted)
