Product Description

Technical Specification:

COMPLIANCE:

• EN 54-24 Certified No

PHYSICAL:

• Colors Black
• Enclosure Material Baltic birch plywood
• Grille 16-gauge (1.5 mm) perforated steel, powder-coated finish
• Suspension/Mounting 3-point quick-pin rigging
• Product Dimensions (H×W×D) 11.9 in × 31.2 in × 18.1 in (303 mm × 793 mm × 461 mm)
• Net Weight 64.0 lb (29.0 kg)

PERFORMANCE:

• Frequency Range (-10 dB) 59 Hz – 18,000 Hz
• Coverage, Horizontal 100°
• Calculated Maximum SPL @ 1 m 121 dB (low frequency), 125 dB (high frequency) continuous / 127 dB (low frequency), 131 dB (high frequency) peak
• Nominal Impedance 8 Ω (low frequency) + 6 Ω (high frequency)
• Power Handling, long-term continuous 450 W (low frequency), 100 W (high frequency)
• Power Handling, Peak 1800 W (low frequency), 400 W (high frequency)
• Sensitivity (SPL/1 W at 1 m) 94 dB (low frequency), 105 dB (high frequency)
• Coverage, Vertical 20°

TRANSDUCERS:

• Crossover 750 Hz, acoustic, requires active 2-way crossover in DSP
• High-Frequency 4 × Bose Professional EMB2S extended-high frequency neodymium compression driver, 2 in (51 mm) voice coil
• Low-Frequency 2 × Bose Professional SM8 neodymium 8 in (203 mm) woofers, 3 in (76 mm) voice coil
• Warranty Period 5 years
