Product Description

Technical Specification:

PHYSICAL:

• Colors Black
• Enclosure Material Baltic birch plywood
• Environmental Protected-outdoor usage, IP43
• Grille Perforated steel, powder-coated finish
• Ingress Protection IP43
• Logo Rotatable
• Suspension/Mounting M10 threaded inserts
• Product Dimensions (H×W×D) 457 mm × 457 mm × 370 mm (18.0 in × 18.0 in × 14.6 in)
• Net Weight 20.1 kg (44.3 lb)
• Shipping Weight 23.4 kg (51.6 lb)

PERFORMANCE:

• Frequency Range (-10 dB) 48 Hz – 20,000 Hz
• Coverage, Horizontal 110°
• Calculated Maximum SPL @ 1 m 126 dB continuous, 132 dB peak
• Nominal Impedance 8 Ω, passive / 8 Ω (LF) + 8 Ω (HF), bi-amp
• Power Handling, long-term continuous 300 W
• Power Handling, Peak 2400 W
• Recommended Signal Processing Bose Professional presets available but not required
• Sensitivity (SPL/1 W at 1 m) 96 dB
• Coverage, Vertical 60°

TRANSDUCERS:

• Crossover Internal passive or external bi-amp
• High-Frequency 1 × compression driver, 1.7 in (44 mm) voice coil
• Low-Frequency 1 × 12.0 in (305 mm) woofer
