Product Description

Technical Specification:

AMPLIFICATION:

• Number of Channels 2
• Power Class Class D
• THD+N 0.1% maximum (30 Hz – 15 kHz)

AUDIO INPUTS, ANALOG:

• Input Channels 2
• Connectors (1) XLR-1/4-in combo, (1) RCA stereo pair, (1) 1/4-in TS/TRS
• Sensitivity Options -Infinity to +34 dB, line / -Infinity to +54 dB, mic, -Infinity to +26 dB, RCA / -Infinity to +20 dB, 1/4-in
• Phantom Power No

ELECTRICAL:

• AC Power Connector IEC
• AC Power Input 100-240 V, 50/60 Hz

GENERAL:

• Software Applications No

INDICATORS AND CONTROLS:

• Controls, Rear Panel Volume level, Signal input select, Front LED function select, EQ V
• LED Status Indicators (1) power/fault LED, (2) signal/clip LEDs, (1) limit LED, (1) configurable front-panel LED

INTEGRATED DSP:

• DSP-Enabled Yes
• Processing Functions Output EQ, limiter

PHYSICAL:

• Colors Black
• Enclosure Material High impact composite materials
• Grille Steel, powder-coated finish
• Operating Temperature Range 0 °C to 50 °C (32 °F to 122 °F)
• Product Dimensions (H×W×D) 26.1 in × 14.6 in × 13.1 in (663 mm × 371 mm × 333 mm)
• Net Weight 44.5 lb / 20.2 kg
• Shipping Dimensions (H×W×D) 32.5 in × 20.0 in × 18.5 in (826 mm × 508 mm × 470 mm)
• Storage Temperature -30 °C to 70 °C (-22 °F to 158 °F)
• Shipping Weight 55.0 lb (24.9 kg)

PERFORMANCE:

• Frequency Range (-10 dB) 43 Hz – 20 kHz
• Coverage, Horizontal 100°
• Calculated Maximum SPL @ 1 m 132 dB
• Power Handling, Peak 1000 W
• Coverage, Vertical 40°

TRANSDUCERS:

• Crossover 600 Hz, 4th-order Butterworth
• Driver Protection Dynamic limiter
• High-Frequency 8 × 2.25 in (57 mm) mid-high-frequency drivers
• Low-Frequency 1 × 12 in (305 mm) low-frequency driver
• Warranty Period 2 years
